77 ORNG OR120 – Tone Match Gen2 Presets and Captures

Line 6 Patches available for Helix (floor, LT, and Native), HX Stomp (including Stomp XL), and POD Go.

This download includes patches for Helix, HX Stomp, and POD Go. Please make sure to import the appropriate patch for your hardware – they are not interchangeable.

• ORNG OR120 WT S – This patch uses the IR’s and is meant for guitars with single coils.
• ORNG OR120 WT H – This patch uses the IR’s and is meant for guitars with humbuckers.
• NOTE: The HX Stomp and POD Go folders include ‘FX” patches. These patches include the additional effects blocks from the full Helix patch.

SIGNAL FLOW AND EFFECTS

1. Input
2. Compressor
3. Drives: KOT, Klon, Horizon Precision Drive
4. Volume – mapped to EXP 2
5. Amp
6. IR
7. EQ
8. Chorus
9. Tremolo
10. Delays: 1/8 delay, Dotted 8th delay, Dual stereo delay
11. Reverbs: Hall (subtle), Dynamic Hall (huge)
12. Output

The HX Stomp and POD Go patches cannot fit all the effects into a single patch. For those platforms, we include the amp and essential effects in the main patches, and then we include the additional effects blocks in the ‘FX’ patches. Feel free to mix and match the additional ‘FX’ blocks into the main patches to suite your needs.

SNAPSHOTS

• Snapshot 1: CLEAN-ISH. Base clean tone
• Snapshot 2: OVERDRV. Engages a KOT drive
• Snapshot 3: RHYTHM. Increases gain on the amp
• Snapshot 4: SOLO. Big lead tone
• Snapshot 5: AMBIENT. Clean tone with lots of delay and verb
• Snapshot 6: CHOR CLEAN. Clean tone with chorus
• Snapshot 7: P&W LEAD. Big lead tone with lots of delay and reverb
• Snapshot 8: SWELLS. All the ambient stuff

POD Go:

• Snapshot 1: CLEAN. Base clean tone
• Snapshot 2: DRIVE. Stage 1 drive tone
• Snapshot 3: SOLO. Lead tone
• Snapshot 4: AMBIENT. Ambient clean tone

NOTE: The HX Stomp patches do not include Snapshots.

Fractal Presets available for Axe-FX III, FM3, and FM9

This download includes patches for Axe-FX III, FM3, and FM9. Please make sure to import the appropriate patch for your hardware – they are not interchangeable.

• ORNG OR120 WT S – This patch uses the user cabs and is meant for guitars with single coils.
• ORNG OR120 WT H – This patch uses the user cabs and is meant for guitars with humbuckers.

NOTE: The FM3 folder includes an ‘FX” patch. This patch includes the additional effects blocks from the full Axe-FX and FM9 patches. Feel free to substitute any of these effects blocks into the main patch to suite your needs.

SIGNAL FLOW AND EFFECTS

1. Input
2. Compressor
3. Pitch
4. Drives
5. Volume
6. Amp
7. User Cab
8. Tremolo
9. Chorus
10. Delays: 1/8 delay, Dotted 8th delay, Dual stereo delay
11. Reverbs: Hall (subtle), Dynamic Hall (huge)
12. Output

The FM3 presets cannot fit all the effects into a single patch. For that platform, we include the amp and essential effects in the main presets, and then we include the additional effects blocks in the ‘FX’ preset. Feel free to mix and match the additional ‘FX’ blocks into the main patches to suite your needs.

SCENES

• SCENE 1: CLEAN-ISH. Base clean tone
• SCENE 2: OVERDRIVE. Stage 1 drive tone
• SCENE 3: RHYTHM. Big rhythm tone
• SCENE 4: SOLO. Lead tone
• SCENE 5: AMBI CLEAN. Clean tone with lots of delay and verb
• SCENE 6: CLEAN CHORUS. Clean tone chorus
• SCENE 7: P&W LEAD. Lead tone with big delay and reverb
• SCENE 8: SWELLS. Solo tone with fewer reverb and delay effects

In the output block under the ‘Scene Levels’ tab, we’ve adjusted the output level for various scenes. Adjust these to suite your needs.

TONEX AMP CAPTURE PRESETS – Compatible with the Tonex/Amplitube Software and the TONEX pedal

For Tonex, we have captured the amp through its entire gain range of the amp. The Amp Model Presets and are numbered – higher numbers mean more gain. The ‘Edge of Breakup’ settings that we like to use with a pedal board are usually the 2 and/or 3 capture.

QUAD CORTEX CAPTURES

For Quad Cortex, we have captured the amp through its entire gain range of the amp. The captures and are numbered – higher numbers mean more gain. The ‘Edge of Breakup’ settings that we like to use with a pedal board are usually the 2 and/or 3 capture.

ALL-IN-ONE PRESETS

Also included are gig-ready (Sunday morning ready, to be more precise) all in one presets utilizing captures of this amp and our drive pedals. We’ve included separate presets for both single coil quipped and humbucker equipped guitars. You can use these presets in both Scene and Stomp mode, and they cover a ton of sonic territory.

HOW DO YOU GET THE CAPTURES?

When you place your order, we will need to manually send you the captures through the ‘Cortex Cloud’ app by Neural DSP, available for both iOS and Android devices. First, you need to have the app installed and you must have an account through the app (go here to create an account and access the app).

This is how we will send you the captures:

1. Please include your Cortex Cloud app username in the ‘Notes’ field when checking out. If you do not include this, we cannot send you the captures. After we receive your order, we (WorshipTutorials) will follow you on the app.
2. Follow ‘WorshipTutorials’ on the Cortex Cloud app. This will make us ‘friends’ through the app :). If you are not following us, we cannot send you the captures.
3. After we receive your order, and we ‘Friends’ on the app, we will send you the captures through the app. We bundle the captures into presets, so you will receive one (or more) presets that include all the captures. You will find the captures in the ‘Shared with me’ section on your Quad Cortex.
4. Please allow up to 5 business days for us to send you the captures. Most orders will be fulfilled within two business days or less. This fulfillment process must happen manually – we will do our best to get you the files quickly. Once the NDSP marketplace opens, this process may change.

KEMPER PROFILES AND PERFORMANCES – Compatible with the Kemper Head and Stage products

For Kemper, we have profiled the amp through its entire gain range of the amp. The Profiles and are numbered – higher numbers mean more gain. The ‘Edge of Breakup’ settings that we like to use with a pedal board are usually the 2 and/or 3 profiles.

KEMPER PERFORMANCES

We’ve also included fully featured Kemper performances with options for both single coils and humbuckers.

HEADRUSH PRIME (not compatible with other Headrush units)

For Headrush Prime, we’ve included both rigs (patches) and amp clone(s).

SIGNAL FLOW AND EFFECTS

1. Input
2. Compressor
3. Pitch
4. Drives
5. Volume
6. Amp Clone
7. Tremolo
8. Chorus
9. Delays: 1/8 delay, Dotted 8th delay, Dual stereo delay
10. Reverbs: Subtle and Ambient
11. Output

BUTTON CONFIGURATION

We’ve programmed the buttons on the Headrush Prime to act like a traditional pedalboard. You’ll see individual effects mapped to the different buttons and labeled appropriately. If you’d like to make changes, the process is simple – the Headrush Prime manual provides great documentation if you’d like to create scenes or other button mapping.
